DockAssist<sup>®</sup> Vessel Tracking & Monitoring System

DockAssist® Vessel Tracking & Monitoring System

Why DockAssist

Berthing and docking aid systems are used in ports and terminals to monitor and record the vessel approach process.

They provide assistance to the terminal operators, the pilot and the tug crews during the vessel maneuvers and at the same time they record all the available data for future use and documentation purposes.

DockAssist® by Metratek is an advanced Vessel Tracking and Monitoring System developed to incorporate functionality far beyond the conventional laser-only based berthing aid systems.

What makes DockAssist® pioneer is its ability to monitor and record simultaneously geometric, positional and speed information for all the vessels within a terminal area, even outside the inherently limited laser range.

System Overview

Laser Sensors

DockAssist uses state-of-the-art laser sensors to accurately measure the distance of the vessel during berthing. Laser sensors are ATEX (EN 60079-0:2009, EN 60079-1, EN60079-31:2009) and Class I Eye Safe.

Central Monitoring System


The Central Monitoring System is generally equipped the following components:

  • Computer System with OS
  • Automation Hardware/Software
  • Display Monitor
  • Portable Display Units /Smartpads
  • DockAssist Software



ADAS Data Decoding & Analysis

Automatic identification of vessels and their dynamic data (location, direction, course, speed, rate of turn) as decoded by the ADAS allows the system to track and log the full path followed by the vessel. For each specific positional fix the system logs additionally all the associated dynamic data.

Automatic Data Logging

Automatic registration of vessels is possible since all ship static data are obtained and entered without operator intervention in the database long before the vessel even approaches the port facility (several nautical miles VHF range). The operators will never have to enter anything in regard to the vessels. Typing and data entry errors are eliminated.

Live Metrics Calculation

DockAssist® provides live metrics that assist proper positioning of the tanker and alignment of its manifolds to the associated loading arms. Metrics include offset, vertical distance and vessel heading displayed both to the system console and the portable units (pagers, smart pads).

Visualization

Real-time on-screen animation of the berthing process based on the real time data and the actual dimensions of the vessel. Visualization includes tug boats (and their dynamic data) and all the vessels in the area.
There are no blind spots, uncertainty or false readings caused by the limitations of laser-only technology.

Wave & Tide Sensor

The wave/tide sensor is a purpose-built, accurate pressure sensor capable to provide various readings such as wave height, tide level, wave amplitude, temperature, irregularity and other.

Current Sensor

The Current Sensor operation is based on the Doppler Effect. It is a rugged, true vector averaging sensor for measuring current speed and direction in the sea. The sensor has built-in compass and tilt sensor and may also output sea temperature. The measurable speed range is 0 to 300 cm/s. It has no moving parts achieving excellent performance in unstable areas such as in the wave zone close to surface.

Weather Station

Weather station includes an integrated sensor suite (ISS) that wirelessly transmits data to a display console. The ISS is autonomous without any need for power supply and can be pole-mounted.

  • Wireless
  • Rain Collector
  • Anemometer
  • Weather Proof
  • Radiation Shield
  • Temperature / Relative Humidity
  • Wind Direction
  • Solar Panel



AVS Monitoring & Recording

DockAssist® AVS integrates video and audio sources into the BAS and is operated from the CMS.

Advanced Detection and Automation System (ADAS)

The ADAS® is a highly integrated patented system, operational since 2008 that consists the actual core of the DockAssist® Vessel Tracking and Monitoring System.

Key Features

Visualization

  • Real-time on-screen animation
  • Display of all vessels in the terminal area
  • Visualization of tug boats and their dynamic data
  • Virtual laser function: calculation and display of vessels position even when outside the laser range
  • Standard and satellite map option

Playback & Reporting

  • Individual playback function for multiple vessel tracks
  • Playback of any given time period with configurable speed
  • Full reporting and printing with print preview option
  • Berthing records can be filtered and exported in .kml format

Automation & Alerting

  • Autonomous and unattended recording of berthing
  • Direct registration of vessels and logging of all static and voyage data
  • Automatic identification of vessels and their dynamic data (location, direction, course, speed, ROT)
  • Custom maneuver zones for automatic event and alert triggering

SmartAlign®

SmartAlign® feature provides live metrics for the proper alignment of the vessel manifolds to the loading arms on the jetty.



DockAssist® System Console

  • ADAS® Virtual Vessel Display
  • SmartAlign® feature provides live metrics for the proper alignment of the vessel manifolds to the loading arms on the jetty
  • VTrack® feature enables vessel position interrogation
  • Multiple berth management
  • Simultaneous berthing, playback and drift-off operations
  • Multiple speed limit sets per laser sensor
  • Wind compensated speed limits
  • User configurable geometric details of jetties, sensors and interconnections
  • On-demand display of weather and marine data
  • Open standards, data can be sent in standard XML/JSON format to any other system
  • Test function for all system devices

Safety Increase Rates

Safer maneuvers & faster berthing

Tracking & Visualization of the entire berthing process

Complete documentation in case of accident or damage
